Hexagon screw full thread DIN 961 M14x1.50x70-10.9
Code: 838580
Product detailed description
No product's description available
Additional parameters
| Category: | Fasteners > hexagon head screws > fine full thread DIN 961 > steel 10.9 without treatment |
|---|---|
| Weight: | 0.101 kg |
| CSN standard: | 021103 |
| Diameter D (mm): | M14x1,50 |
| DIN standard: | 961 |
| Fortress class: | 10,9 |
| Head shape: | hexagonal |
| Height k (mm): | 8,8 |
| ISO standard: | ~8676 |
| Length L (mm): | 70 |
| Material: | steel |
| Pitch: | 1,50 |
| Surface finish: | without modification |
| Thread type: | metric fine |
| Width e (mm): | 24,49 |
| Width s (mm): | 22 |
